DPE-400

Download PDF

(218.55 KB)

Specifications

Rated Voltage: 24 V
Flow Rate: 400 ml/min
Working Pressure Range: 0 ~ 1000 mbar
Outlet Pressure: 3 bar
Self-Priming Pressure: 400 mbar
Maximum Current: 345 mA
Rated Operating Time: Continous
Life Expectancy: 500 h
Inlet and Outlet: 5.4 mm O.D. straight nipple
Insulation Classification: F calss equivalent
Mounting Dimensions (L x W): 19 x 26 mm
Gross Weight: 187 g
Motor: DC Brush Motor

Airflow & Power Consumption
(click to enlarge)

Sketch Drawing and Mounting Dimensions Diagram (mm)

DPE-400
